Concave convex Acoustic panels
Our concave/convex acoustic panels will add depth to your interior design. By mixing the two shapes side by side, you can create a one-of-a-kind cosy atmosphere.
Description
Presentation
TEMPO’s product range includes concave/convex acoustic panels delivering high-performance soundproofing.
The variations in panel thickness gives you a host of opportunities to create your own, bespoke design. With our 130 shades and digital printing, our CONCAVE/CONVEX panels, with their one-of-a-kind shape, invite you to let your imagination run free to add incredible depth to your spaces.
Composition
Galvanized steel frame
50 mm-thick TEMPO acoustic absorbent made from 100% recycled polyester fibres
Non-woven blackout fabric
Removable, washable cover covering 5 or 6 sides depending on the installation system used
A choice of 4 coverings, 130 colours, other colours on request, digital printing
Technical characteristics
Fire class: Euroclass B-s2, d0, French M1, based on the coverings
All the components are sourced in the European Union
TEMPO products are designed and manufactured at our production site located in Maine et Loire (49), France.
All the components are VOC A+ classified
Acoustic performance: αw = 1
Installation system
Horizontally suspended by 4 stainless steel cables
Vertically-secured to the wall on rails, magnets, screws
Horizontally-secured to the ceiling (with safety spring to prevent the panel from falling)
Vertically suspended from the ceiling by 2 stainless steel cables (6 sides covered)
Vertically suspended from the ceiling to the ground (6 sides covered, invisible stainless steel cables running through the panel)
Other installation systems available based on specifications
Options
Recess for light added into the panels
Panels assembled on the ceiling and/or wall
Variable panel thickness from 50 to 150 mm
Other options possible based on specifications
Sizes
Length: 1,000 mm / 1,200 mm / 1,500 mm
Width: 500 mm / 800 mm
The different mounting systems for our concave/convex acoustic panels
Ceiling-secured
Wall-secured
Magnetic
Suspended by 4 cables
Make your desires a reality with digital printing. A design, a logo, a color, a shape? We realize all your desires! Digital printing is done directly on our fabric “La” Toile.
Design style tips
These two highly-original, complementary shapes can be ceiling-suspended, wall-secured, suction-padded, installed on magnets, etc. and can be used separately. When you combine them together, they give your spaces a brand new perspective and still ensure maximum acoustic performance.
What do our customers love about our concave/convex acoustic panels?
Complementary shapes
Our concave/convex acoustic panels match perfectly side by side. Both add incredible depth to your interior design and, at the same time, efficiently enhance your acoustic comfort.
One-of-a-kind look
The variations in panel thickness gives you a host of opportunities to create your own, bespoke design.
Optimal sound absorption
Our concave/convex acoustic panels add extra volume and offer you streamlined soundproofing, which means your acoustic comfort is efficiently enhanced.
Downloads
Would you like to find out more about our concave/convex acoustic panels?
